Sieve Filter

Product Details

Place of Origin: China

Brand Name: COWELL

Model Number: LWZ

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Hard Carton

Delivery Time: 3-7 working days

Payment Terms: T/T

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                    truck sieve filter, tank truck filter screen, heavy-duty sieve filter


Diameter:	2“， 3” & 4“	Material:	Aluminum
Working Pressure:	6 Bar	Flow Rate:	600-1500L/Min

Diameter:	2“， 3” & 4“
Material:	Aluminum
Working Pressure:	6 Bar
Flow Rate:	600-1500L/Min

Description

Sieve Filter

Description

Sieve filter is used for filtering various oils. It prevents solids and impurities when loading oils.

Easy to tank out filter element and eliminate impurities.

It can be installed on various pipes. Compact structure, light weight, good filtering.

Easy to install and clean.

Characteristics

Die cast aluminum structure, with good strenth and oxidation treatment.
The filter element is easy to clean and dismount
Filter screen alignments position assembly
Easy to dismount the cover
Removing all latches and bolts components, easy maintenance
Dissassebly and assembly without special tools
Flange meeets TTMA standard

Material

Body: Aluminum

Spring: Stainless Steel, Copper

Seal: NBR

Hardware: Steel

Technical Specification
Model	LWZ-50	LWZ-80	LWZ-100
Size	2"	3"	4"
Working pressure	6 Bar	6Bar	6Bar
Connection mode	Flange 4 holes	Flange 4 or 8 Holes	Flange 4 Holes
Flow rate	600-1500L/Min
Filter mesh	80M or 60M ( others tailor made)
Medium	Diesel, Gasoline, Kerosene
